03DPCG5B

Overview

The Delta Electronics 03DPCG5B is a single-phase EMC/EMI power line filter designed for chassis mounting. It operates at 115VAC or 250VAC with a current rating of 3A and supports 50/60Hz frequencies. The component features a two-stage switching transient filter configuration with quick connect terminals. It holds CSA, UR, and VDE certifications and complies with RoHS3 standards.

Feature Summary

• Two-stage switching transient filtering architecture
• Chassis mount installation style
• Quick connect terminal interface

Applications

• General industrial equipment EMI suppression
• Power supply input filtering
• Electronic device noise reduction

Procurement Notes

Verify the End of Life notification dated June 1, 2026, which indicates discontinuation by August 31, 2026. Confirm final availability status before ordering as stock may be limited. Ensure compatibility with existing chassis mounting requirements and terminal specifications during procurement planning.

Selection Notes

Select this model for applications requiring single-phase EMI suppression at 3A. Verify voltage ratings match the system's 115VAC or 250VAC operation. Ensure chassis mounting space is available. Check certification requirements against local regulatory standards for CSA, UR, and VDE compliance.

Part Context

This component belongs to the DP series of power line filters from Delta Electronics. It is categorized under power condition sub-components. The product is classified as a switching transient filter intended for electromagnetic interference mitigation in electrical circuits.

Replacement Considerations

Consult official documentation for confirmed substitute part numbers due to the End of Life status. Evaluate alternative models within the same manufacturer series that maintain identical electrical ratings and mounting configurations.
