Product Detailed Parameters
- Description：LINE FILTER 115V/250VAC 3A CHASS
- Series：DP
- Mfr：Delta Electronics
- Package：Box
- Filter Type：Single Phase
- Configuration：Two Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：115V, 250V
- Current：3:00 AM
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：CSA, UR, VDE
- Operating Temperature：-
- Mounting Type：Chassis Mount
- Termination Style：Quick Connect
- Inductance：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The Delta Electronics 03DPCG5CM is a single-phase power line filter designed for chassis mounting. It features a two-stage filtering configuration to manage electromagnetic interference. The component supports rated voltages of 115 VAC and 250 VAC with a current rating of 3 A. It operates at frequencies of 50 Hz and 60 Hz. The unit utilizes quick-connect terminals for electrical connections.
Feature Summary
- Two-stage filtering architecture for enhanced noise suppression
- Chassis mount installation style for secure integration
- Quick-connect terminal interface for simplified wiring
Applications
- Industrial equipment power conditioning
- Medical device power supply filtering
- General purpose electronic systems requiring EMI reduction
Procurement Notes
Verify the End-of-Life status before procurement, as the manufacturer has issued discontinuation notifications. Confirm that existing inventory or last-time buy options meet project requirements. Ensure compatibility with existing chassis mounting hardware and quick-connect terminal specifications during replacement planning.
Selection Notes
Select this component when a two-stage power line filter is required for 115/250 VAC applications. Ensure the system design accommodates chassis mounting and quick-connect termination methods. Verify that the 3 A current rating aligns with the load requirements and that the operating frequency matches the 50/60 Hz supply network.
Part Context
This component belongs to the DP series of power line filters manufactured by Delta Electronics. The series includes various models with different current ratings and terminal configurations. The 03DPCG5CM specifically addresses low-current applications requiring robust EMI protection in a compact chassis-mountable form factor.
Replacement Considerations
Check for direct substitutes within the DP series with compatible voltage and current ratings. Verify mechanical dimensions and terminal types to ensure fitment. Consider alternative manufacturers offering similar two-stage filtering performance if Delta Electronics units are unavailable.
