057.01013.00

$2,170.92

Description：LINE FILTER 277V/480VAC 10A CHAS
Series：57
Mfr：Astrodyne TDI
Package：Box

SKU:d7121624f379 Category: Power Line Filter Modules Brand: Astrodyne TDI

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LINE FILTER 277V/480VAC 10A CHAS
Series：57
Mfr：Astrodyne TDI
Package：Box
Filter Type：Three Phase (Delta)
Configuration：-
Voltage - Rated DC：-
Voltage - Rated AC：277V, 480V
Current：10:00 AM
Frequency - Operating：50/60Hz
Applications：General Purpose
Approval Agency：CE, cURus, SEMKO
Operating Temperature：-40°C ~ 85°C
Mounting Type：Chassis Mount
Termination Style：Threaded Post (M6)
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：2.2 kV
Voltage - Rated AC (Phase to Phase)：-

Download product information

057.01013.00

Overview

The Astrodyne TDI 057.01013.00 is a three-phase delta EMC/EMI power line filter rated for 10 A at 277 V or 480 V and 50/60 Hz. It utilizes threaded M6 posts for termination and is designed for general-purpose applications.

Feature Summary

Three-phase delta configuration
Threaded post termination

Applications

General purpose filtering

Procurement Notes

Verify the specific voltage rating (277 V vs 480 V) and current capacity against the system requirements. Confirm that the M6 threaded post interface matches the mounting hardware. Ensure the component meets the necessary EMI/EMC standards for the intended deployment environment.

Selection Notes

Select this model for three-phase systems requiring delta configuration. The 10 A rating suits moderate load applications. Verify compatibility with the operating frequency of 50/60 Hz and ensure the chassis allows for secure mounting via M6 threaded posts.

Part Context

This component belongs to the Astrodyne TDI power line filter modules series, which provides EMI/EMC suppression solutions across various industrial and commercial sectors.
