Product Detailed Parameters
- Description：LINE FILTER 250VAC 1A CHASS MNT
- Series：82
- Mfr：Astrodyne TDI
- Package：Box
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：250V
- Current：1:00 AM
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：cURus, VDE
- Operating Temperature：-25°C ~ 85°C
- Mounting Type：Chassis Mount
- Termination Style：IEC Inlet-C14, Quick Connect
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：1.45 kV
Download product information
Overview
The Astrodyne TDI 082.00101.00 is a filtered AC power entry module designed for panel mount installation. It features an IEC-320 C-14 connector and quick connect termination type. The unit is rated for 1 A current and 250 VAC voltage, operating at 50/60 Hz frequencies. This component integrates standard filtering capabilities with a fused circuit protection mechanism. It utilizes a male DPST switch configuration for circuit control.
Feature Summary
- Integrates standard EMI filtering with fused circuit protection
- Features a male DPST illuminated switch for circuit control
- Utilizes IEC-320 C-14 receptacle for standardized connection
Applications
- General purpose electronic equipment power entry
- Medical device power interfaces
- Industrial control panels requiring filtered input
Procurement Notes
Verify the specific suffix requirements for your application, as variants like -RSI may differ in packaging or minor specifications. Confirm that the 1A rating and fused protection align with your system's safety standards. Ensure the panel cutout dimensions match the physical constraints of your enclosure design before finalizing procurement.
Selection Notes
Select this module when a combined filter, fuse, and switch solution is required in a compact form factor. The 1A rating suits low-power applications where integrated protection simplifies bill-of-materials. Consider the quick-connect termination for ease of assembly compared to soldered alternatives.
Part Context
This component belongs to the 082 series of AC power entry modules from Astrodyne TDI. The series focuses on providing essential power management functions including filtering and switching in a single panel-mount unit. It serves as a critical interface between the mains supply and internal DC or AC circuits.
Replacement Considerations
Direct replacements must match the 1A current rating, 250VAC voltage, and IEC C-14 connector type. Verify that substitute units include equivalent filtering performance and fused protection if required by the original design specifications.
FAQ
Does the 082.00101.00 include a built-in fuse?
Yes, the datasheet indicates that this module includes a fused circuit protection mechanism.
What is the switch configuration for this model?
The unit features a male DPST (Double Pole Single Throw) switch configuration.
