Product Detailed Parameters
- Description：LINE FILTER 250VAC 3A CHASS MNT
- Series：82
- Mfr：Astrodyne TDI
- Package：Box
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：250V
- Current：3:00 AM
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：cURus, VDE
- Operating Temperature：-25°C ~ 85°C
- Mounting Type：Chassis Mount
- Termination Style：IEC Inlet-C14, Quick Connect
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：1.45 kV
Download product information
Overview
The Astrodyne TDI 082.00301.00-LS is a single-phase EMC/EMI line filter module designed for integration into AC power input systems. It features an IEC C14 inlet connector and utilizes quick connect terminals for circuit attachment. The unit is rated for a continuous current of 3 A at voltages up to 250 VAC, operating within standard 50 Hz and 60 Hz frequency ranges. This component incorporates internal filtering capabilities to suppress electromagnetic interference while maintaining compliance with safety standards.
Feature Summary
- Integrated EMI/EMC filtering stage for noise suppression
- IEC C14 receptacle interface for standardized connection
- Quick connect termination style for rapid assembly
Applications
- Single-phase AC power input conditioning
- Electromagnetic interference suppression in electronic equipment
- Power line filter modules for industrial control systems
Procurement Notes
Verify the specific suffix LS against official manufacturer documentation to confirm exact electrical characteristics and mechanical dimensions. Ensure compatibility with existing panel cutouts and terminal configurations before procurement. Cross-reference the datasheet for environmental ratings and certification requirements relevant to the target deployment region.
Selection Notes
Select this model when a compact, single-stage filtered inlet is required for low-current applications. The 3 A rating suits devices with moderate power consumption. Verify that the quick connect pin spacing matches the PCB or wire harness design. Confirm that the integrated fuse capability meets the system's overcurrent protection strategy without requiring external components.
Part Context
This component belongs to the Astrodyne TDI power line filter module series, which provides combined inlet and filtering functions. These modules are engineered to reduce board space and simplify assembly by integrating passive filtering elements directly into the power entry point. The series supports various current ratings and termination styles for diverse industrial and commercial needs.
Replacement Considerations
Direct substitutes must match the 3 A rating, 250 VAC voltage, IEC C14 interface, and quick connect termination. Verify that any alternative offers equivalent attenuation performance and physical footprint. Consult manufacturer cross-reference lists for validated equivalents.
