082SM.00600.00

Overview

The Astrodyne TDI 082SM.00600.00 is a single-phase EMC/EMI power line filter module rated for 6 A at 250 VAC and 50/60 Hz. It features a snap-in mounting style with quick connect terminals and an IEC-320 C14 connector. The unit includes a standard single-stage filter, a DPST illuminated switch, and a one-pole fuse holder.

Feature Summary

• Integrated single-stage EMI/EMC filtering for noise suppression
• Built-in DPST illuminated switch for circuit control
• Includes one-pole fuse holder for overcurrent protection
• Snap-in panel mount design for rapid installation

Applications

• Medical equipment power entry
• General purpose industrial electronics
• Single-phase AC power distribution systems

Procurement Notes

Verify the specific suffix configuration against the manufacturer datasheet to ensure compatibility with required regulatory standards and terminal types. Confirm that the snap-in form factor fits the target enclosure dimensions before procurement.

Selection Notes

Select this component when a combined solution for filtering, switching, and fusing is required in a compact snap-in format. Ensure the 6 A current rating and 250 VAC voltage limit align with the system's electrical requirements.

Part Context

This part belongs to the Astrodyne TDI 082 series of filtered power entry modules. These units are designed for applications requiring integrated noise reduction and safety components within a standardized IEC connector interface.

Replacement Considerations

Consult official substitution guides for equivalent snap-in modules with matching 6 A ratings and single-stage filtering characteristics.
