Product Detailed Parameters
- Description：LINE FILTER 480VAC CHASSIS MOUNT
- Series：TDT
- Mfr：Delta Electronics
- Package：Box
- Filter Type：Three Phase (Delta)
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：480V
- Current：-
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：-
- Operating Temperature：-
- Mounting Type：Chassis Mount
- Termination Style：Terminal Block
- Inductance：7.6mH
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The Delta Electronics 08TDT2 is a power line filter module designed for industrial applications. It operates at a voltage rating of 480 VAC and supports a current rating of 8 A. The unit features chassis mount construction with terminal block connections. It belongs to the TDT series and complies with RoHS standards, ensuring environmental safety in electronic assemblies.
Feature Summary
- Provides electromagnetic interference filtering for power lines
- Features robust chassis mount design for stable installation
- Utilizes terminal block connections for secure wiring
Applications
- Industrial machinery power supply protection
- Factory automation system noise suppression
- Electrical cabinet EMC compliance enhancement
Procurement Notes
Verify the exact datasheet version before procurement, as specifications may vary by manufacturing batch. Confirm RoHS compliance status directly with the manufacturer or authorized distributor. Ensure the chassis mounting dimensions match your enclosure requirements. Check for any specific lead time constraints associated with the TDT series production schedule.
Selection Notes
Select this component when an 8 A rated filter is required for 480 VAC three-phase systems. Compare against other TDT series models if higher current capacity is needed. Ensure the terminal block interface suits existing wiring infrastructure. Validate that the physical footprint fits within the designated control panel space.
Part Context
This module is part of Delta Electronics' TDT series, which focuses on passive components for power quality improvement. The series provides standardized solutions for reducing conducted emissions in industrial environments. It complements other Delta automation products by ensuring clean power delivery to sensitive control equipment.
Replacement Considerations
Consult official Delta documentation for direct substitutes within the TDT series. Verify electrical ratings and mounting compatibility before considering third-party alternatives. No public substitute part numbers are confirmed in available sources.
