1-6609036-0

Overview

The TE Connectivity Corcom Filters model 1-6609036-0 is a single-phase EMC/EMI line filter designed for commercial applications. It supports a rated current of 10 A at 250 VAC and operates within the 50/60 Hz frequency range. The unit features a single-stage filtering configuration and utilizes wire lead termination for circuit connection. This component is intended for chassis or panel mounting to suppress electromagnetic interference in power lines.

Feature Summary

• Provides single-stage EMI/RFI suppression for AC power lines
• Utilizes wire lead termination for direct circuit integration
• Designed for commercial-grade electromagnetic compatibility

Applications

• Commercial electronic equipment power input stages
• Industrial control systems requiring EMI suppression
• General-purpose AC power line filtering

Procurement Notes

Verify the specific part number 1-6609036-0 against official TE Connectivity documentation to confirm current availability and manufacturing status. Ensure that the wire lead termination style matches the design requirements, as this variant differs from quick-connect or screw-terminal options within the same series. Cross-reference certification marks such as CSA, UL, and VDE with local regulatory standards before finalizing procurement decisions.

Selection Notes

Select this component when a single-stage filter solution is sufficient for the target application's noise environment. The 10 A rating at 250 VAC defines the maximum operational limits. Consider the wire lead termination method during PCB or harness design, as it requires soldering or crimping rather than panel-mount terminals. Confirm that the physical dimensions and mounting style align with the enclosure constraints.

Part Context

This component belongs to the TE Connectivity Corcom Filters series, which specializes in power line filters for commercial and industrial use. The product identifier 1-6609036-0 specifically denotes a single-phase unit with wire leads, distinguishing it from other configurations in the lineup that may feature different terminal types or higher current ratings.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source data. Verify compatibility with alternative models by matching electrical ratings, stage configuration, and termination style through official manufacturer cross-reference tools.
