Product Detailed Parameters
- Description：LINE FILTER 50A CHASSIS MOUNT
- Series：FCD
- Mfr：TE Connectivity Corcom Filters
- Package：Box
- Filter Type：Three Phase (Delta)
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：-
- Current：50 A
- Frequency - Operating：50/60Hz
- Applications：Regenerative Motor Drive
- Approval Agency：UR
- Operating Temperature：-10°C ~ 40°C
- Mounting Type：Chassis Mount
- Termination Style：Terminal Block
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：277 V
- Voltage - Rated AC (Phase to Phase)：480 V
Download product information
Overview
The TE Connectivity Corcom Filters model 1-6609974-6 is a three-phase EMC/RFI power line filter designed for industrial applications. It features a rated AC voltage of 480 VAC and a current rating of 50 A. The unit operates at frequencies of 50/60 Hz and utilizes a terminal block termination type for secure electrical connections. Designed for chassis mounting, this single-stage filter ensures compliance with UL and CSA safety standards. It supports Delta wiring configurations (3 wire + ground) and includes a leakage current specification of 630 uA to maintain system safety.
Feature Summary
- Provides effective electromagnetic interference suppression for three-phase power systems
- Supports robust chassis mounting for stable industrial installation
- Utilizes terminal block connections for reliable high-current handling
Applications
- Industrial machinery power conditioning
- Three-phase motor drive protection
- Factory automation equipment filtering
Procurement Notes
Verify the specific datasheet version corresponding to part number 1-6609974-6 before procurement. Confirm that the required voltage and current ratings match your system's operational parameters. Ensure compatibility with chassis mounting dimensions and terminal block specifications. Check for regional availability restrictions as supply status may vary by location.
Selection Notes
Select this component when a three-phase delta configuration is required for 480 VAC systems. Ensure the application demands a 50 A continuous current rating. Verify that chassis mounting is feasible within the enclosure design. Confirm that terminal block termination aligns with existing wiring infrastructure requirements.
Part Context
This component belongs to the TE Connectivity Corcom FCD series of power line filters. The series is engineered for industrial environments requiring reliable EMI/RFI suppression. The FCD series typically offers various current ratings and mounting options to suit different power distribution needs.
Replacement Considerations
Consult official TE Connectivity documentation for verified substitute part numbers. Cross-reference technical specifications such as current rating, voltage, and physical dimensions before considering alternatives.
