1-6609974-8

Overview

The TE Connectivity Corcom Filters model 1-6609974-8 is a three-phase EMC/EMI line filter designed for industrial power applications. It supports a rated current of 110 A and operates at voltages up to 480 VAC or 50/60 Hz. The unit features a single-stage configuration with flanged chassis mounting and terminal block connections, ensuring robust integration into heavy-duty electrical systems requiring effective noise suppression.

Feature Summary

• Provides three-phase EMI/RFI noise attenuation for delta configurations
• Engineered for high-current industrial power distribution environments
• Features durable flanged chassis mounting for secure panel installation

Applications

• Industrial motor drives and variable frequency drives
• Heavy machinery power supply units
• Manufacturing equipment requiring strict electromagnetic compatibility

Procurement Notes

Verify the specific voltage rating and phase configuration against your system requirements before ordering. Confirm that the terminal block connection style matches your wiring infrastructure. Ensure the flanged mounting dimensions align with your enclosure specifications to guarantee proper fit and mechanical stability during operation.

Selection Notes

Select this component when three-phase noise suppression is required for high-amperage circuits. Consider the terminal block interface if screw-type connections are preferred over quick-connect styles. Evaluate the physical footprint to ensure the flanged mount fits within the designated chassis space without obstructing adjacent components.

Part Context

This part belongs to the TE Connectivity Corcom FCD series, which specializes in high-performance three-phase filtering solutions. The series is recognized for handling substantial current loads while maintaining compact form factors suitable for dense industrial panels. It complements other Corcom filters by offering specialized delta-phase capabilities.

Replacement Considerations

FN2080A-10-06 is listed as a similar alternative by distributors, though current ratings may differ. Verify technical compatibility carefully before substitution.
