10017251-112240ELF

Product Detailed Parameters

• Description：CONN FFC TOP 11POS 0.3MM R/A
• Series：SFYL-U
• Mfr：Amphenol ICC (FCI)
• Package：Tape & Reel (TR)
• Flat Flex Type：FFC
• Mounting Type：Surface Mount, Right Angle
• Connector/Contact Type：Contacts, Top
• Number of Positions：11
• Pitch：0.012" (0.30mm)
• Termination：Solder
• FFC, FCB Thickness：0.20mm
• Height Above Board：0.047" (1.20mm)
• Locking Feature：Flip Lock
• Cable End Type：Notched
• Contact Material：Copper Alloy
• Contact Finish：Gold
• Housing Material：Thermoplastic, Glass Filled
• Actuator Material：Thermoplastic
• Features：Low Insertion Force (LIF)
• Voltage Rating：200V
• Operating Temperature：-25°C ~ 85°C
• Material Flammability Rating：UL94 V-0
