100KEBS10BFPD

Overview

The TE Connectivity Corcom Filters 100KEBS10BFPD is a three-phase power line filter designed for industrial applications. It features a single-stage configuration with a current rating of 100 A and voltage ratings of 440 VAC and 520 VAC. The unit operates at frequencies of 50 Hz and 60 Hz, utilizing chassis mount installation and screw termination. This component provides electromagnetic interference mitigation for high-power systems.

Feature Summary

• Single-stage three-phase EMI/RFI filtering architecture
• High-capacity 100 A current handling capability
• Chassis mount design with screw termination

Applications

• Industrial automation machinery
• Three-phase motor drives
• Power distribution units

Procurement Notes

Verify the specific datasheet version as this component may be subject to obsolescence notices. Confirm that the Delta configuration matches the system requirements. Ensure compliance with UL and CSA certifications prior to integration into final equipment designs.

Selection Notes

Select this model for high-current three-phase environments requiring robust chassis-mounted filtration. Evaluate leakage current specifications against safety standards. Compare performance metrics with alternative series such as KESS or KEMS if Wye configurations are required instead of Delta.

Part Context

This part belongs to the Corcom KEB series of power line filters. It is engineered for general-purpose industrial use, offering reliable noise suppression in demanding electrical environments. The series supports various current ratings and mounting styles to accommodate diverse system architectures.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
