Product Detailed Parameters
- Description：LINE FLTR 440VAC 100A CHASS MNT
- Series：KEP-BS
- Mfr：TE Connectivity Corcom Filters
- Package：Box
- Filter Type：Three Phase (Wye)
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：440V
- Current：100 A
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：CSA, UL
- Operating Temperature：-25°C ~ 85°C
- Mounting Type：Chassis Mount
- Termination Style：Terminal Block
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The 100KEPS10ABSW is a three-phase superior performance EMI filter manufactured by TE Connectivity / Corcom. It is rated for 440 VAC and supports a continuous current of 100 A at operating frequencies of 50 Hz and 60 Hz. The unit features chassis mount installation with quick connect and screw termination types. Leakage current is specified at 11 mA. The component carries UL and CSA compliance certifications.
Feature Summary
- Provides superior performance electromagnetic interference filtering for three-phase power lines
- Designed for high-current industrial applications up to 100 amperes
- Supports flexible integration through combined quick connect and screw terminal options
Applications
- Industrial machinery power conditioning
- Three-phase motor drive systems
- Commercial building electrical infrastructure
Procurement Notes
Verify the specific part number against official manufacturer documentation before procurement, as availability status may vary by region. Confirm that the required voltage and current ratings align with the system design specifications. Ensure that the chassis mounting dimensions and terminal configurations are compatible with the intended enclosure layout. Check for any updated regulatory compliance requirements relevant to the deployment location.
Selection Notes
Select this component when a three-phase EMI filter capable of handling 100 A at 440 VAC is required. The choice depends on the need for superior performance filtering characteristics in industrial environments. Verify that the physical dimensions fit the available chassis space. Ensure that the termination style meets the wiring harness or busbar connection requirements of the assembly.
Part Context
This model belongs to the KEP series of power line filters from TE Connectivity / Corcom. The series is designed for robust electromagnetic compatibility in demanding power distribution scenarios. The specific suffix indicates the configuration and terminal type associated with this particular rating within the product family.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided source material. Consult the manufacturer's official cross-reference documentation for verified alternatives.
