100KEPS10BBSW

Overview

The 100KEPS10BBSW is a three-phase single-stage power line filter manufactured by TE Connectivity Corcom. It is rated for 100 A current and 520 VAC voltage at 50/60 Hz operating frequencies. The unit features chassis mounting with terminal block connections. It operates within a temperature range of -25 °C to +85 °C. Dimensions are 350 mm length, 160 mm width, and 92 mm height.

Feature Summary

• Three-phase EMI/EMC filtering capability
• Single-stage attenuation design
• Chassis mount construction

Applications

• Industrial power conditioning systems
• Electrical equipment requiring EMI suppression
• General purpose power line filtration

Procurement Notes

Verify component authenticity through authorized TE Connectivity channels due to obsolete lifecycle status. Confirm technical specifications against official datasheets before integration. Check for RoHS compliance documentation. Ensure replacement parts meet identical electrical ratings and mechanical dimensions for system compatibility.

Selection Notes

Select this model for applications requiring 100 A three-phase filtering at 520 VAC. Verify chassis mounting requirements and terminal block interface compatibility. Consider thermal management capabilities within the specified operating temperature range. Evaluate space constraints against physical dimensions.

Part Context

This component belongs to the KEP series of power line filters from TE Connectivity Corcom. The series provides electromagnetic interference suppression for industrial power systems. The specific model addresses high-current three-phase applications requiring robust chassis-mounted solutions.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material.
