10112690-G01-07ALF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 10112690-G01-07ALF is a Minitek 2.00mm blind mate header connector designed for board-to-wire applications. It features a 7-position configuration with a vertical orientation and surface mount termination. The connector utilizes a 2.00mm pitch, black insulator, and gold-plated contacts to ensure reliable signal transmission in compact electronic assemblies.

Headers, Male Pins Feature Summary

• Supports blind mating for simplified assembly processes
• Integrates signal and power capabilities within a single system
• Features a modular design accommodating various connection types

Headers, Male Pins Applications

• Data communication equipment interconnects
• Industrial application wiring harnesses
• Compact consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official Amphenol documentation to confirm pin count, contact plating specifications, and mounting style. Ensure compatibility with mating receptacles from the same Minitek series. Confirm RoHS compliance status and moisture sensitivity level requirements prior to final procurement decisions.

Headers, Male Pins Selection Notes

Select this component when space optimization is critical due to its 2.00mm pitch offering significant area savings. Choose this model for applications requiring robust signal integrity alongside power delivery. Consider the blind mate feature for automated assembly lines where precise alignment tools are unavailable.

Headers, Male Pins Part Context

This part belongs to the Minitek family, a versatile connector system by Amphenol ICC (FCI). The series provides solutions for board-to-board, wire-to-board, and flat cable connections. It is characterized by high density and reliability, widely used in modern telecommunications and computing infrastructure.

Headers, Male Pins FAQ

What is the primary advantage of the blind mate design?

It allows for easy insertion without visual alignment, streamlining the assembly process.

Does this connector support both signal and power?

Yes, the Minitek system is designed to integrate both signal and power contacts efficiently.
