Headers, Male Pins Overview

The Amphenol ICC (FCI) 10112690-G03-05ULF is a Minitek header connector featuring a 2.00mm pitch and 10 positions in a double-row configuration. Designed for surface mount technology, it utilizes right-angle mounting with male pin contacts. The component supports board-to-board and wire-to-board applications, operating within a temperature range of -40°C to 125°C and rated for 650V.

Headers, Male Pins Feature Summary

• Double-row header design for compact board-to-board and wire-to-board interconnections
• Right-angle surface mount termination for efficient PCB layout utilization
• Gold-plated copper alloy contacts ensuring reliable signal transmission
• Thermoplastic housing providing structural integrity and insulation

Headers, Male Pins Applications

• Consumer electronics internal interconnects
• Industrial control system circuit boards
• Data processing equipment connections
• Communication device signal routing

Headers, Male Pins Procurement Notes

Verify the specific suffix 'G03' against official datasheets to confirm contact plating thickness and material specifications. Ensure RoHS compliance documentation matches current regulatory requirements. Confirm that the right-angle SMD footprint aligns precisely with the target PCB design constraints before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when space-constrained designs require high-density interconnects with a 2.00mm pitch. The right-angle form factor is optimal for vertical stacking or limited profile applications. Verify that the 650V rating and 2A current capacity meet the specific circuit requirements for the intended application environment.

Headers, Male Pins Part Context

This part belongs to the Amphenol Minitek series, known for space-saving solutions in electronic assemblies. The Minitek line offers various pitch options, with this model utilizing the 2.00mm standard. It represents a robust option for general-purpose connectivity needs across multiple industrial and commercial sectors.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 10-position, 2-row, 2.00mm pitch headers from the same manufacturer family, such as the 10112690-G03-10ULF, provided the position count and mechanical dimensions are verified.
