10112690-G03-08ULF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 10112690-G03-08ULF is a Minitek series connector header designed for wire-to-board applications. It features a surface mount, right-angle configuration with 16 positions and a 2.00mm pitch. The component utilizes male pins with a square contact type and black thermoplastic insulation. Rated for 3A current and 200V voltage, it operates within a temperature range of -55°C to +125°C. The contacts are copper alloy posts finished with tin plating.

Headers, Male Pins Feature Summary

• Right-angle surface mount design for compact PCB integration
• Minitek series construction with glass-filled thermoplastic insulation
• Male pin contact type suitable for wire-to-board connections

Headers, Male Pins Applications

• Wire-to-board interconnections
• Surface mount PCB assembly
• Electronic device internal connectivity

Headers, Male Pins Procurement Notes

Verify the specific part number against official Amphenol documentation to confirm the 16-position count and right-angle orientation. Ensure compatibility with the required 2.00mm pitch and surface mount footprint. Check that the tin-plated copper alloy contacts meet the necessary environmental and electrical standards for the intended application.

Headers, Male Pins Selection Notes

Select this component when a right-angle, surface-mount header is required for wire-to-board applications. The 2.00mm pitch and 16-position capacity define the spatial and connectivity constraints. Consider the operating temperature range and current rating to ensure suitability for the specific electronic environment.

Headers, Male Pins Part Context

This part belongs to the Amphenol Minitek series, which provides high-density interconnect solutions. The 10112690 series specifically offers right-angle headers for efficient board space utilization. The G03 suffix typically indicates specific packaging or reel configurations within the product line.

Headers, Male Pins Replacement Considerations

Cross-reference with other Amphenol FCI Minitek series headers having identical 2.00mm pitch, 16 positions, and right-angle surface mount characteristics. Verify mechanical dimensions and contact finish compatibility before substitution.
