10118615-205005LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) part number 10118615-205005LF is a BergStik header connector featuring a vertical, breakaway design. It contains five positions with a 2.54mm pitch. The contacts are rated for 3A current and utilize copper alloy material with square contact shapes. The housing is constructed from thermoplastic insulation. Key dimensions include a 0.500-inch post length and a 0.225-inch mating length. The component supports a maximum operating temperature of +125°C.

Headers, Male Pins Feature Summary

• Features a breakaway design allowing users to cut or break the connector to length to suit specific application profiles.
• Vertical header configuration provides space-efficient mounting on printed circuit boards.

Headers, Male Pins Applications

• General electronic interconnections requiring customizable length headers
• Industrial control systems utilizing standard 2.54mm pitch interfaces
• Consumer electronics assemblies with vertical board-to-board connection needs

Headers, Male Pins Procurement Notes

Verify the exact pin count and pitch against the datasheet specifications before ordering. Confirm that the thermoplastic housing material meets the thermal requirements of the target environment. Ensure compatibility with mating terminals regarding the square contact shape and 3A current rating. Check for RoHS compliance status if required by project regulations.

Headers, Male Pins Selection Notes

Select this component when a vertical header with customizable length is required. The 2.54mm pitch is standard for many legacy and general-purpose designs. Consider the 3A current rating for power distribution needs within the assembly. The breakaway feature offers flexibility in inventory management and assembly line efficiency.

Headers, Male Pins Part Context

This part belongs to the BergStik series from Amphenol ICC (FCI). The series is characterized by its versatile breakaway design, which allows for easy customization of connector lengths during assembly. This approach reduces the need for maintaining multiple SKUs for different lengths, streamlining supply chain operations for manufacturers using standard pitch connectors.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify mechanical fit and electrical ratings if considering alternative vendors. Contact the manufacturer for official obsolescence notices or recommended replacements if this part becomes unavailable.
