10118615-215001LF is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Amphenol ICC (FCI). Its product description is CONN HEADER VERT 15POS 2.54MM. Review the specifications below when checking this part for your BOM.
Headers, Male Pins specifications for 10118615-215001LF
- Description：CONN HEADER VERT 15POS 2.54MM
- Series：BERGSTIK® II
- Mfr：Amphenol ICC (FCI)
- Package：Bag
- Connector Type：Header, Breakaway
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：15
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Board
- Shrouding：Unshrouded
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.318" (8.08mm)
- Contact Length - Post：0.130" (3.30mm)
- Overall Contact Length：0.548" (13.92mm)
- Insulation Height：0.100" (2.54mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold or Gold, GXT™
- Contact Finish Thickness - Mating：15.0µin (0.38µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-65°C ~ 130°C
- Ingress Protection：-
- Material Flammability Rating：-
- Insulation Color：-
- Current Rating (Amps)：3A
- Voltage Rating：-
Headers, Male Pins datasheet and documents for 10118615-215001LF
Headers, Male Pins Overview
The Amphenol ICC (FCI) part number 10118615-215001LF is a Micro HDMI connector component. It features a single port with 19 positions designed for surface mount installation. The connector utilizes right-angle termination and includes through-hole mounting tabs for secure PCB attachment. This component is manufactured by Amphenol ICC (FCI) and is classified under USB, DVI, and HDMI interconnect devices.
Headers, Male Pins Feature Summary
- Micro HDMI interface configuration
- Surface mount right-angle design
- Through-hole mounting tabs
Headers, Male Pins Applications
- Portable electronic devices
- Mobile communication hardware
- Compact multimedia equipment
Headers, Male Pins Procurement Notes
Verify the specific ordering suffix to confirm the exact packaging type, such as tape and reel or cut tape, as these variations affect handling procedures. Ensure that the RoHS compliance status matches your assembly requirements. Confirm availability directly with authorized distributors, as stock levels fluctuate rapidly for active components.
Headers, Male Pins Selection Notes
Select this component when a low-profile, high-density connection is required for portable applications. The right-angle orientation facilitates compact board layouts. Verify that the mechanical footprint aligns with the target PCB design and that the current ratings meet the system's power transmission needs.
Headers, Male Pins Part Context
This component belongs to the HDMI connector family produced by Amphenol ICC (FCI). The manufacturer specializes in high-performance interconnect solutions for data communications and consumer electronics. This specific model supports digital audio and video transmission standards within compact form factors suitable for modern mobile devices.
Headers, Male Pins Replacement Considerations
Consult official cross-reference lists from Amphenol ICC (FCI) for verified substitute part numbers. Generic HDMI connectors may not match the precise mechanical dimensions or contact plating specifications required for reliable performance.
