10118650-407002LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) part number 10118650-407002LF is a right-angle header connector from the PwrBlade series. It features a 2.54mm pitch and contains 7 positions arranged in a single row. The connector utilizes through-hole termination for secure board mounting. Contact surfaces are finished with tin, lead-free plating to ensure reliable electrical conductivity. Designed for server and storage applications, it supports signal transmission within a temperature range of -40°C to 105°C.

Headers, Male Pins Feature Summary

• Right-angle design facilitates compact board edge connections
• Through-hole termination ensures robust mechanical stability
• Lead-free tin plating provides corrosion resistance

Headers, Male Pins Applications

• Server backplane interconnects
• Storage system power distribution
• Telecommunications equipment

Headers, Male Pins Procurement Notes

Verify RoHS compliance status as the specific suffix indicates lead-free characteristics. Confirm that the right-angle orientation matches the PCB layout requirements. Ensure mating connectors align with the specified 2.54mm pitch and single-row configuration. Check for any specific handling instructions regarding the through-hole soldering process.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle header is required for signal integrity in high-density environments. Consider the thermal rating of -40°C to 105°C for industrial or commercial operating conditions. Evaluate the single-row layout against available board space constraints. Compare against other PwrBlade variants if higher current capacity or additional rows are needed.

Headers, Male Pins Part Context

This connector belongs to the PwrBlade family, designed for high-reliability data center applications. It integrates signal and power capabilities within a standardized form factor. The product supports modern server architectures requiring stable connectivity under thermal stress. Its design emphasizes ease of assembly and long-term durability in demanding electronic systems.

Headers, Male Pins Replacement Considerations

No direct public substitute part numbers are confirmed for this specific variant. Cross-reference with other Amphenol ICC headers sharing the same pitch and row count. Verify mechanical dimensions and pinout compatibility before considering alternative suppliers.

Headers, Male Pins FAQ

What is the contact material finish?

The contacts feature a tin, lead-free plating finish.

Is this connector suitable for high-temperature environments?

Yes, it operates within a temperature range of -40°C to 105°C.
