10118884-405003LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) part number 10118884-405003LF is a rectangular header connector designed for surface mount applications. It features a single row with five positions and a pitch of 2.54mm (0.100 inches). The connector utilizes right-angle through-hole termination to secure the component to the printed circuit board. This specific assembly includes male pins, providing a reliable interface for mating with corresponding receptacles or cables in electronic systems.

Headers, Male Pins Feature Summary

• Right-angle design facilitates compact board layout and efficient space utilization within constrained enclosures.
• Through-hole termination ensures robust mechanical stability and durable solder joints on the target substrate.
• Male pin configuration provides standardized contact interfaces compatible with various mating receptacle types.

Headers, Male Pins Applications

• General purpose electronic assemblies requiring reliable signal interconnection
• Industrial control modules needing stable board-to-board connections
• Consumer electronics utilizing standard pitch header configurations

Headers, Male Pins Procurement Notes

Verify the exact suffix against the manufacturer's current datasheet to confirm pin count and orientation specifications. Ensure compatibility with existing PCB footprint dimensions and soldering profiles. Cross-reference the RoHS status and material composition requirements with your specific project standards before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle connection is required for a five-position interface. The 2.54mm pitch offers broad compatibility with standard industry cabling and mating connectors. Consider the through-hole mounting method if higher mechanical strength is preferred over surface mount alternatives for vibration-prone environments.

Headers, Male Pins Part Context

This component belongs to the broader family of rectangular headers produced by Amphenol ICC (FCI), formerly Framatome Connectors International. These connectors are engineered to provide dependable electrical pathways in diverse electronic environments. The product line emphasizes durability and consistent performance across various industrial and commercial applications.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 5-position count, 2.54mm pitch, right-angle orientation, and through-hole termination style. Verify that alternative manufacturers offer identical pin geometry and housing dimensions to ensure seamless integration without modifying the existing PCB design.
