10119109-326014LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) part number 10119109-326014LF is a vertical header connector designed for surface mount termination. It features a 26-position configuration with a 2.54mm pitch spacing between contacts. The component utilizes a single row arrangement and includes a mating contact length of 0.540 inches (13.72mm). This specific interconnect solution is engineered to provide reliable electrical connections within compact electronic assemblies requiring standard board-to-board or wire-to-board interfaces.

Headers, Male Pins Feature Summary

• Vertical orientation design for direct surface mount integration onto printed circuit boards
• Single row header configuration providing standardized 2.54mm contact spacing
• Zero insertion force compatibility through precise pin alignment mechanisms

Headers, Male Pins Applications

• General purpose electronic assembly interconnections
• Industrial control system signal routing
• Consumer electronics internal wiring harnesses

Headers, Male Pins Procurement Notes

Verify the exact suffix designation against official manufacturer documentation to ensure correct packaging and material specifications. Confirm that the lead time aligns with project schedules, as availability may fluctuate based on production cycles. Cross-reference the RoHS compliance status with current regulatory requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a vertical header with a 2.54mm pitch is required for space-constrained applications. Ensure the PCB footprint matches the specified dimensions for proper solder joint formation. Evaluate the mechanical stability needs against the single-row design limitations for high-vibration environments.

Headers, Male Pins Part Context

This connector belongs to the broader family of Amphenol ICC interconnect solutions, which focus on providing robust connectivity options for diverse industrial and commercial markets. The product line emphasizes reliability and ease of assembly, catering to manufacturers seeking standardized components that meet stringent quality benchmarks for mass production environments.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing PCB layouts if considering alternative vendors. Consult official engineering change notices for any potential obsolescence warnings related to this specific model.

Headers, Male Pins FAQ

What is the contact spacing for this connector?

The connector features a standard 2.54mm pitch spacing between adjacent contacts.

How many positions does this header have?

This specific model contains 26 individual contact positions arranged in a single row.
