10119109-330009LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) part number 10119109-330009LF is a vertical header connector designed for through-hole mounting. It features a 30-position configuration with a 2.54mm pitch, suitable for board-to-board or cable-to-board interconnections. The connector utilizes phosphor bronze contacts with gold plating to ensure reliable signal transmission and low contact resistance. Constructed with a polyamide (PA66) housing, it offers mechanical stability and thermal resistance. This component is RoHS compliant and intended for use in various electronic applications requiring robust connectivity.

Headers, Male Pins Feature Summary

• Vertical orientation for efficient PCB space utilization
• Gold-plated phosphor bronze contacts for durability
• Polyamide housing material for thermal stability

Headers, Male Pins Applications

• Consumer electronics assemblies
• Industrial control systems
• Telecommunications equipment

Headers, Male Pins Procurement Notes

Verify the specific suffix and packaging details directly with the manufacturer or authorized distributors, as ordering information may vary. Confirm that the requested quantity matches the standard reel or tube specifications provided by Amphenol ICC. Ensure compliance with current environmental regulations such as RoHS requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this connector when a vertical, 30-pin header with a 2.54mm pitch is required. Consider the through-hole mounting style and the specific contact material properties for your application's electrical and mechanical needs. Evaluate the housing material compatibility with your assembly process temperatures.

Headers, Male Pins Part Context

This component belongs to the general family of FCI headers and connectors, which are widely used in the electronics industry for reliable interconnection solutions. Amphenol ICC provides a broad range of such components to support diverse design requirements across multiple sectors.

Headers, Male Pins Replacement Considerations

Consult official cross-reference guides from Amphenol ICC or authorized distributors to identify verified substitute part numbers. Do not assume generic equivalents without verifying pin count, pitch, and mounting specifications.
