10119109-530022LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) part number 10119109-530022LF is a vertical header connector designed for through-hole mounting on printed circuit boards. It features a single row with 30 positions and a standard 2.54mm pitch. The connector utilizes male pin contacts suitable for wire-to-board or board-to-board interconnections. Constructed with durable materials, it supports reliable electrical signal transmission in various electronic assemblies.

Headers, Male Pins Feature Summary

• Vertical orientation design facilitates compact PCB layout integration
• Through-hole termination ensures secure mechanical attachment to the substrate
• Single-row configuration simplifies wiring and assembly processes

Headers, Male Pins Applications

• General purpose electronic equipment interconnects
• Industrial control system signal routing
• Consumer electronics internal connections

Headers, Male Pins Procurement Notes

Verify the complete part number including the suffix to ensure correct contact plating and material specifications. Confirm RoHS compliance status matches project requirements. Check for end-of-life notices as distribution availability may vary. Ensure mating connectors match the 2.54mm pitch and 30-position count for proper interface compatibility.

Headers, Male Pins Selection Notes

Select this component when a vertical, single-row header is required for low-to-medium density signal applications. The 2.54mm pitch is standard for general-purpose electronics. Consider mechanical retention needs for through-hole mounting versus surface mount alternatives. Evaluate current carrying capacity requirements against the specific contact material properties defined in the official datasheet.

Headers, Male Pins Part Context

This component belongs to the Amphenol ICC (FCI) portfolio of interconnect solutions. FCI, now part of Amphenol, specializes in high-reliability connectors for datacom, industrial, and consumer markets. This specific header type represents a standard solution for basic connectivity needs within larger electronic systems requiring robust and cost-effective interconnection methods.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify cross-reference options directly with the manufacturer or authorized distributors to ensure equivalent electrical and mechanical specifications before substitution.
