10119109-916021LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) part number 10119109-916021LF is a vertical header connector featuring 16 positions with a 2.54mm pitch. Designed for through-hole mounting, this component utilizes square pins with a tin-plated surface finish to ensure reliable electrical contact. The housing is constructed from black insulating material rated at UL94 V-0 for flammability. It belongs to the BERGSTIK II series and employs a push-pull locking mechanism for secure mating. The connector supports a maximum current rating of 3A per contact and operates within a temperature range of -55°C to 105°C.

Headers, Male Pins Feature Summary

• Vertical board-to-board configuration with 2.54mm spacing
• Push-pull locking system for secure connection retention
• Tin-plated contacts for corrosion resistance
• UL94 V-0 rated black thermoplastic housing

Headers, Male Pins Applications

• Industrial control systems
• Consumer electronics assemblies
• Data processing equipment
• Telecommunications infrastructure

Headers, Male Pins Procurement Notes

Verify that the specific ordering suffix matches the required pin count and orientation. Confirm RoHS compliance status as indicated in the official datasheet. Ensure the supplier provides traceable documentation for the tin-plated contact finish. Cross-reference the manufacturer's latest lifecycle status to confirm availability before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a vertical, unshrouded header with a push-pull lock is required for 2.54mm pitch applications. Consider the 3A current rating and -55°C to 105°C operating range against environmental demands. Evaluate the through-hole termination method against PCB layout constraints and mechanical stability requirements for the specific assembly.

Headers, Male Pins Part Context

This connector is part of the BERGSTIK II series produced by Amphenol ICC (FCI). The series is known for providing robust interconnect solutions for various electronic applications. As an FCI product, it adheres to high standards for signal integrity and mechanical durability, serving as a standard interface solution in broader connectivity portfolios.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 16-position count, 2.54mm pitch, vertical orientation, and push-pull locking feature. Verify that alternative components maintain identical current ratings and thermal specifications to ensure functional equivalence in existing designs.
