10119110-516002LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) part number 10119110-516002LF is a right-angle header connector belonging to the Minitek® Multipitch™ series. It features a 16-position configuration with a 2.54mm pitch. The component utilizes male pin contacts and is designed for surface-mount termination. This connector is intended for wire-to-board applications, providing reliable electrical interconnection in compact electronic assemblies.

Headers, Male Pins Feature Summary

• Right-angle design facilitates space-efficient board layout
• Minitek Multipitch series ensures consistent signal integrity
• Surface-mount termination supports automated assembly processes

Headers, Male Pins Applications

• Wire-to-board interconnections
• Compact electronic device assemblies
• Signal transmission circuits

Headers, Male Pins Procurement Notes

Verify the specific suffix against official manufacturer documentation to confirm exact contact plating and material specifications. Ensure compatibility with existing PCB footprint designs before procurement. Confirm current lifecycle status through authorized distributors to avoid obsolete components.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle header is required for dense circuit layouts. The 2.54mm pitch offers standard spacing for common wiring harnesses. Evaluate mechanical retention needs as surface-mount variants rely on solder joints for primary fixation.

Headers, Male Pins Part Context

This connector is part of the Minitek Multipitch family from Amphenol ICC (FCI). The series provides versatile solutions for various interconnect needs, balancing performance with cost-effectiveness. It serves as a critical interface element in modern electronics manufacturing.

Headers, Male Pins Replacement Considerations

Cross-reference with other Minitek Multipitch headers sharing identical pin counts and pitch dimensions. Verify mechanical height and mounting hole alignment to ensure direct substitution without PCB redesign.
