10119332-401A04LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 10119332-401A04LF is a BergStik board-to-board connector header. It features a 2.54mm pitch, single row configuration with four positions. The component is an unshrouded horizontal header designed for surface mount termination. It includes locating pegs to ensure precise alignment during assembly.

Headers, Male Pins Feature Summary

• Unshrouded horizontal header design
• Single row configuration
• Surface mount termination
• Integrated locating pegs

Headers, Male Pins Applications

• Board-to-Board interconnects
• Mezzanine connections

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix and RoHS compliance status directly with the manufacturer or authorized distributors before procurement. Confirm that the current revision matches the required mechanical footprint and electrical specifications for the target application.

Headers, Male Pins Selection Notes

Select this component when a low-profile, single-row connection is required. Ensure the mating connector supports the 2.54mm pitch and unshrouded interface. Verify that the PCB layout accommodates the surface mount pads and locating peg holes.

Headers, Male Pins Part Context

This part belongs to the BergStik family of connectors from Amphenol FCI. These headers are widely used in compact electronic assemblies where space efficiency and reliable signal transmission are critical requirements.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available.
