10119332-403-05LF

$0.18

Description：CONN HEADER SMD R/A 5POS 2.54MM
Series：BERGSTIK®
Mfr：Amphenol ICC (FCI)
Package：Tape & Reel (TR)

SKU:69780c636c04 Category: Headers, Male Pins Brand: Amphenol ICC (FCI)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

10119332-403-05LF is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Amphenol ICC (FCI). Its product description is CONN HEADER SMD R/A 5POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 10119332-403-05LF

Description：CONN HEADER SMD R/A 5POS 2.54MM
Series：BERGSTIK®
Mfr：Amphenol ICC (FCI)
Package：Tape & Reel (TR)
Connector Type：Header, Breakaway
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：5
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Surface Mount, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.420" (10.67mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.150" (3.81mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：78.7µin (2.00µm)
Contact Finish - Post：Tin
Contact Material：Copper Alloy
Insulation Material：Thermoplastic
Features：Board Guide
Operating Temperature：-65°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：Black
Current Rating (Amps)：3A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for 10119332-403-05LF

10119332-403-05LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) part number 10119332-403-05LF is a BergStik board-to-board connector. It features an unshrouded horizontal header with surface mount termination and locating pegs. The connector has a single row configuration with five positions and utilizes a 2.54mm (0.100in) pitch.

Headers, Male Pins Feature Summary

Provides reliable electrical connections between circuit boards using a single-row header design.
Incorporates locating pegs to ensure precise alignment during the assembly process.
Designed for surface mount termination to facilitate automated manufacturing integration.

Headers, Male Pins Applications

General electronic equipment interconnections
Industrial control systems
Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to confirm exact pin count, pitch, and termination style. Confirm current availability status directly with authorized distributors or the manufacturer, as supply conditions may vary. Ensure compatibility with existing PCB footprint requirements before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a low-profile, single-row board-to-board connection is required. The 2.54mm pitch offers standard spacing suitable for general signal routing. Verify that the horizontal orientation and surface mount profile align with the mechanical constraints of the target enclosure and assembly workflow.

Headers, Male Pins Part Context

This component belongs to the BergStik series by Amphenol ICC (formerly FCI). The series provides versatile interconnect solutions for various electronic applications. The product line emphasizes durability and ease of installation in compact designs.
