10119333-103-11LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 10119333-103-11LF is a BergStik® series unshrouded header connector designed for surface mount applications. It features an 11-position, single-row configuration with a 2.54mm pitch. The component utilizes male pin contacts made of phosphor bronze, finished with gold over nickel to ensure reliable signal transmission and corrosion resistance. Rated for 3A per contact at 110V, it employs a right-angle SMT termination style for efficient board space utilization. The housing is constructed from thermoplastic material rated UL94 V-0 for flammability, providing structural integrity in compact electronic assemblies.

Headers, Male Pins Feature Summary

• Right-angle surface mount termination facilitates dense circuit board layouts
• Gold-plated phosphor bronze contacts ensure durable electrical connectivity
• Unshrouded design allows for flexible mating options with various cable assemblies

Headers, Male Pins Applications

• Consumer electronics internal interconnects
• Industrial control system boards
• Telecommunications equipment modules

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm the exact contact finish thickness and plating specification required for your application environment. Ensure that the surface mount footprint matches the manufacturer's recommended land pattern to guarantee proper solder joint formation during assembly processes.

Headers, Male Pins Selection Notes

Select this component when a right-angle, surface-mount header is required for low-to-medium current signal routing. The 2.54mm pitch offers compatibility with standard ribbon cables and wire harnesses. Consider the unshrouded nature of the design regarding potential short-circuit risks if adjacent conductive surfaces are present on the PCB.

Headers, Male Pins Part Context

This part belongs to the BergStik® family of connectors, which provides versatile connection solutions for various electronic industries. The 10119333 base number indicates a specific row and contact count within the broader product line, standardized for interoperability across different manufacturing environments and supply chains.

Headers, Male Pins Replacement Considerations

Direct cross-replacement requires verifying identical mechanical dimensions and electrical ratings. No official substitute part numbers are publicly confirmed for this specific obsolete or discontinued variant; consult the manufacturer for current equivalent series recommendations.
