10121350-101LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) part number 10121350-101LF is a right-angle header connector designed for surface-mount or through-hole applications. It features a 24-position configuration with a 2.54mm pitch, providing reliable signal transmission in compact electronic assemblies. The connector utilizes a single row of contacts to facilitate efficient board-to-board or cable-to-board interconnections.

Headers, Male Pins Feature Summary

• Right-angle design optimizes vertical space within dense electronic enclosures.
• Standard 2.54mm pitch ensures compatibility with widespread industry wiring and PCB layouts.

Headers, Male Pins Applications

• General-purpose electronic equipment interconnects
• Industrial control system signal routing
• Consumer electronics internal circuit connections

Headers, Male Pins Procurement Notes

Verify the specific contact plating material and termination style against the official datasheet before procurement. Confirm that the right-angle orientation matches the mechanical constraints of the target assembly. Ensure the supplier provides genuine components from authorized channels to guarantee electrical performance and long-term reliability.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle connection is required for 24-channel signal distribution. The 2.54mm pitch offers a balance between density and ease of handling. Consider thermal management requirements during soldering and ensure the housing material meets the operational temperature range of the intended environment.

Headers, Male Pins Part Context

This connector belongs to the standard linear header series produced by Amphenol ICC (FCI). It serves as a fundamental interconnection solution for general electronics, bridging the gap between complex high-speed interfaces and basic power distribution needs in standard commercial hardware.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 24-position count, 2.54mm pitch, and right-angle form factor. Verify pinout compatibility and mechanical mounting hole alignment before cross-referencing alternative manufacturers' equivalent parts.
