10123459-008LF

Overview

The 10123459-008LF is a high-density card edge connector from the PCIe M.2 Gen 5 HPCE series, manufactured by Amphenol ICC (FCI). It provides 67 contacts with a 0.50mm pitch and supports various connector heights ranging from 4.2mm to 8.5mm. Designed for PCIe M.2 Gen 5 applications, this component ensures reliable signal integrity in high-speed data transmission environments.

Feature Summary

• Supports PCIe M.2 Gen 5 high-speed data transmission standards
• Features a compact 0.50mm pitch for high-density board layouts
• Offers flexible height options ranging from 4.2mm to 8.5mm

Applications

• PCIe M.2 Gen 5 storage modules
• High-performance computing expansion cards
• Data center acceleration hardware

Procurement Notes

Verify the specific contact count and height variant against project requirements, as the base part number covers a range of configurations. Confirm RoHS compliance status through official manufacturer documentation prior to integration. Ensure mating interface compatibility with corresponding PCB edge designs.

Selection Notes

Select this connector for applications requiring Gen 5 PCIe signal integrity and dense pin arrangements. Evaluate the available height options between 4.2mm and 8.5mm to match mechanical constraints. Consider thermal management needs associated with high-speed data transfer components in enclosed systems.

Part Context

This component belongs to the HPCE series, which focuses on high-performance card edge solutions. The product line supports evolving interface standards like PCIe M.2 Gen 5, addressing demands for increased bandwidth and miniaturization in modern electronic devices and infrastructure.

Replacement Considerations

No public confirmed substitute part numbers are documented for this specific model. Verify cross-compatibility with existing system designs before considering alternative sources or generic equivalents.
