Product Detailed Parameters
- Description：CONN HEADER VERT 20000POS 2.54MM
- Series：BERGSTIK®
- Mfr：Amphenol ICC (FCI)
- Package：Tape & Reel (TR)
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：Cuttable
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board
- Shrouding：Unshrouded
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.483" (12.26mm)
- Contact Length - Post：0.094" (2.40mm)
- Overall Contact Length：0.677" (17.20mm)
- Insulation Height：0.100" (2.54mm)
- Contact Shape：Square
- Contact Finish - Mating：Tin
- Contact Finish Thickness - Mating：100.0µin (2.54µm)
- Contact Finish - Post：Tin
- Contact Material：Brass
- Insulation Material：Liquid Crystal Polymer (LCP)
- Features：-
- Operating Temperature：-
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：-
- Voltage Rating：-
Download product information
Overview
The Amphenol ICC (FCI) part number 10123500-400003LF is a rectangular header connector belonging to the BERGSTRIP series. It features a vertical mounting style with a 2.54mm (0.100 inch) pin spacing and supports 20,000 contact positions. The component utilizes a through-hole termination method for secure PCB attachment. Designed for high-density applications, this header provides reliable electrical interconnection within industrial and commercial electronic systems requiring substantial I/O capacity.
Feature Summary
- High-density configuration supporting up to 20,000 contact positions
- Vertical orientation facilitates standard board-to-wire harness connections
- Robust construction suitable for demanding industrial environments
Applications
- Industrial control panels
- Data communication equipment
- Commercial aerospace avionics
Procurement Notes
Verify the exact contact count and pitch against official datasheets before procurement. Confirm that the 20,000 position requirement aligns with system design constraints. Ensure compatibility with mating wire harnesses and verify surface finish specifications for solderability requirements in your specific manufacturing process.
Selection Notes
Select this component when high channel density is required within a standard 2.54mm grid layout. Consider the physical dimensions and panel space needed for such a large array. Evaluate thermal management needs due to the high current potential across many contacts. Ensure mechanical stability for the heavy assembly during operation.
Part Context
This connector belongs to the BERGSTRIP family of headers from Amphenol ICC (FCI). These components are widely used in datacom and telecom infrastructure. The series offers various configurations to meet diverse interconnect needs while maintaining consistent performance standards across different product lines.
Replacement Considerations
Check for direct cross-reference part numbers from Amphenol or other manufacturers offering identical 2.54mm pitch headers with equivalent pin counts. Verify mechanical footprint compatibility and electrical ratings before substituting.
