10124782-00002TLF

Overview

The 10124782-00002TLF is a PCI Express female connector manufactured by Amphenol ICC (FCI). It features 98 positions arranged in a dual-row configuration with a 0.050-inch pitch. Designed for surface-mount termination, this component utilizes gold-plated contacts to ensure reliable signal integrity in high-speed data applications. The connector is rated for RoHS compliance and supports standard PCB mounting requirements.

Feature Summary

• Dual-row female contact architecture optimized for PCI Express signal transmission
• Surface-mount termination method for automated assembly integration
• Gold-plated contact surfaces ensuring corrosion resistance and conductivity

Applications

• PCI Express peripheral card edge interfaces
• High-density motherboard expansion slots
• Industrial computing hardware interconnects

Procurement Notes

Verify the specific suffix 'TLF' against the manufacturer's current datasheet to confirm plating specifications and packaging format. Ensure compatibility with the target PCB footprint and reflow profile requirements before finalizing procurement orders.

Selection Notes

Select this component when a high-pin-count, low-profile solution is required for PCI Express applications. Consider the surface-mount orientation and dual-row layout constraints during mechanical design to ensure adequate clearance for mating cards.

Part Context

This part belongs to the Amphenol ICC (FCI) portfolio of high-reliability interconnect solutions. The manufacturer specializes in connectors supporting information technology and communication markets, providing robust signal integrity and power management capabilities for modern electronic systems.

Replacement Considerations

Consult official substitution guides for equivalent 98-position PCIe connectors from the same series. Verify pinout compatibility and mechanical dimensions before implementing any alternative part numbers.
