10127720-023GLF

$0.49

Description：CONN MTK 3.0 DR 02P RA HDR AU
Series：Minitek® Pwr 3.0
Mfr：Amphenol ICC (FCI)
Package：Tray

SKU:e05826c21f62 Category: Headers, Male Pins Brand: Amphenol ICC (FCI)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN MTK 3.0 DR 02P RA HDR AU
Series：Minitek® Pwr 3.0
Mfr：Amphenol ICC (FCI)
Package：Tray
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：-
Number of Positions：2
Number of Rows：2
Row Spacing - Mating：0.118" (3.00mm)
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Locking Ramp
Contact Length - Mating：-
Contact Length - Post：0.126" (3.20mm)
Overall Contact Length：-
Insulation Height：0.285" (7.25mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：15.0µin (0.38µm)
Contact Finish - Post：-
Contact Material：Copper Alloy
Insulation Material：Liquid Crystal Polymer (LCP)
Features：Board Lock, Glow Wire Compliant
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：Varies by Wire Gauge
Voltage Rating：600VAC/DC

Download product information

10127720-023GLF

Overview

The Amphenol ICC (FCI) part number 10127720-023GLF is a Minitek Power 3.0 series right-angle header connector designed for wire-to-board power applications. It features a dual-row configuration with two positions and a 3.00mm mating pitch. The contacts are gold-plated copper alloy pins with a thickness of 15.0µin (0.38µm). Constructed with liquid crystal polymer insulation, the component supports a voltage rating of 600VAC/DC and operates within a temperature range of -40°C to 105°C.

Feature Summary

Right-angle through-hole mounting style for compact board integration
Gold contact finish ensures reliable conductivity and corrosion resistance
Dual-row design accommodates high-density power circuit requirements

Applications

Industrial equipment power distribution
Alternative energy generation systems
Factory automation control units

Procurement Notes

Verify the specific suffix GLF against current manufacturer documentation to confirm plating specifications and material composition. Ensure that the selected variant matches the required pin count and orientation for the target PCB layout. Cross-reference official datasheets for any recent product change notifications regarding manufacturing locations or material updates before finalizing procurement orders.

Selection Notes

Select this component when a low-profile, right-angle power connection is required for small signal or power circuits. The 3.00mm pitch allows for adequate spacing in dense layouts. Consider the gold plating for environments requiring superior contact reliability compared to tin finishes. Verify that the 600VAC/DC rating aligns with the system's electrical requirements.

Part Context

This connector belongs to the Minitek Power 3.0 family produced by Amphenol ICC (FCI), formerly Framatome Connectors International. The series specializes in wire-to-board solutions offering robust performance in industrial and commercial sectors. The brand provides comprehensive interconnect systems known for durability and signal integrity across various environmental conditions.
