10127720-061GLF

Overview

The Amphenol ICC (FCI) 10127720-061GLF is a Minitek® Pwr 3.0 series power header connector designed for wire-to-board applications. It features a dual-row configuration with six positions and a 3.00mm pitch. The component utilizes square male pins with tin plating on both the mating and post surfaces, each measuring 100.0µin (2.54µm). Constructed from copper alloy contacts and black liquid crystal polymer insulation, it supports a rated voltage of 600VAC/DC. The connector employs through-hole right-angle termination and includes board lock and shroud features.

Feature Summary

• Dual-row power header design with four-wall shielding for secure signal integrity
• Board lock mechanism ensures stable mechanical retention during operation
• Compliant with灼热丝 (Glow-wire) specifications for enhanced fire safety
• Right-angle through-hole mounting facilitates compact PCB layout integration

Applications

• Power distribution in industrial control systems
• Wire-to-board connections in consumer electronics
• Signal and power interfaces in data processing equipment

Procurement Notes

Verify the specific suffix GLF indicates lead-free compliance and RoHS adherence as per manufacturer standards. Confirm that the 14-week standard delivery time aligns with project timelines. Ensure the right-angle orientation matches the PCB footprint requirements. Cross-reference the datasheet for current derating curves based on ambient temperature and contact spacing to validate electrical performance under load conditions.

Selection Notes

Select this part when a low-profile, dual-row power connection is required for up to six circuits. The 3.00mm pitch allows for higher current capacity compared to smaller pitches. Consider the right-angle form factor for space-constrained vertical interconnections. Verify compatibility with mating receptacles within the Minitek Pwr 3.0 family. Evaluate thermal management needs given the 600V rating and operating temperature range.

Part Context

This component belongs to the Minitek® Pwr 3.0 series, engineered for robust power and signal transmission. The series offers various pin counts and configurations to support diverse wiring harnesses. It is manufactured by Amphenol ICC (FCI), formerly Framatome Connectors International, known for durable interconnect solutions. The product line emphasizes reliability in harsh environments with high vibration and temperature resistance.
