Product Detailed Parameters
- Description：CONN 3.0MM HEADER DUAL R
- Series：Minitek® Pwr 3.0
- Mfr：Amphenol ICC (FCI)
- Package：Tape & Reel (TR)
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.118" (3.00mm)
- Number of Positions：14
- Number of Rows：2
- Row Spacing - Mating：0.118" (3.00mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Locking Ramp
- Contact Length - Mating：-
- Contact Length - Post：0.126" (3.20mm)
- Overall Contact Length：-
- Insulation Height：0.285" (7.25mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：Flash
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Liquid Crystal Polymer (LCP)
- Features：Board Lock
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：Varies by Wire Gauge
- Voltage Rating：600VAC/DC
Download product information
Overview
The Amphenol ICC (FCI) 10127720-142RLF is a Minitek Power 3.0 series power-to-board header connector. It features a dual-row, right-angle through-hole design with 14 positions and a 3.00mm pitch. The contacts are male pins made of copper alloy with gold plating. Rated for 600VAC and up to 8.5A, it utilizes Liquid Crystal Polymer (LCP) insulation in black. Operating temperature ranges from -40°C to +105°C.
Feature Summary
- Dual-row right-angle through-hole mounting configuration
- Gold-plated male pin contacts for reliable conductivity
- High current and voltage ratings suitable for power distribution
- UL94 V-0 rated LCP housing for thermal stability
Applications
- Server and storage system power distribution
- Telecommunications equipment power boards
- Industrial control board interconnects
- High-density power supply modules
Procurement Notes
Verify the specific suffix 'RLF' against the manufacturer's latest datasheet to confirm gold plating thickness and RoHS compliance status. Confirm availability as this part may be subject to factory special order requirements or limited regional distribution. Cross-reference the 14-position count with mechanical constraints before finalizing procurement.
Selection Notes
Select this component when a high-current, dual-row power connection is required on a PCB edge. The 3.00mm pitch allows for significant spacing between power traces. Ensure the mating socket supports the specified 600VAC rating and that the board layout accommodates the right-angle profile and 7.25mm insulation height.
Part Context
This connector belongs to the Minitek Power 3.0 family, designed for robust power applications. It complements other variants in the 10127720 series which differ by position count, row configuration, and termination style. The series provides standardized interfaces for server and communication infrastructure power delivery systems.
