10127720-222LF

Overview

The Amphenol ICC (FCI) 10127720-222LF is a Minitek Pwr 3.0 series power header connector designed for board-to-cable or wire applications. It features a right-angle through-hole mounting style with a 16-position, 2-row configuration and a 3.00mm mating pitch. The connector utilizes square male pin contacts with tin plating on a copper alloy base, housed in black liquid crystal polymer (LCP). Rated for 600VAC/DC, it includes a four-wall shielded shroud, board lock, and glow-wire compliant insulation rated UL94 V-0.

Feature Summary

• Minitek Pwr 3.0 series construction with LCP insulation for high thermal stability
• Four-wall shielded shroud design providing comprehensive cable protection
• Board lock mechanism ensures secure mechanical retention during assembly
• Glow-wire compliant insulation material meeting strict safety standards

Applications

• Industrial control systems requiring robust power distribution
• Factory automation equipment and instrumentation
• Power supply units and battery management systems
• Heavy machinery and transportation electronics

Procurement Notes

Verify the specific suffix against the manufacturer's current datasheet to confirm exact packaging and termination specifications. Ensure compatibility with mating cables and PCB footprint dimensions before procurement. Confirm that the tin-plated contact finish meets the required environmental resistance for the intended application environment.

Selection Notes

Select this component when a right-angle, high-current power connection is required within a compact form factor. The 3.00mm pitch allows for higher density compared to standard 5.08mm connectors while maintaining significant current capacity. The shielded shroud is essential for applications where cable strain relief and EMI shielding are critical design requirements.

Part Context

This part belongs to the Minitek Pwr 3.0 family, which offers various position counts and mounting styles. It serves as a reliable interconnect solution for industrial environments, balancing electrical performance with mechanical durability. The series is widely used in sectors demanding high reliability and compliance with international safety standards.

Replacement Considerations

Consult official substitution guides for direct replacements. Verify that any alternative part matches the 3.00mm pitch, 16-position count, and right-angle orientation. Ensure the substitute maintains the same voltage rating and shroud configuration to preserve system integrity.
