Product Detailed Parameters
- Description：CONN HEADER VERT 14POS 3MM
- Series：Minitek® Pwr 3.0
- Mfr：Amphenol ICC (FCI)
- Package：Tray,Tray
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.118" (3.00mm)
- Number of Positions：14
- Number of Rows：2
- Row Spacing - Mating：0.118" (3.00mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Kinked Pin, Solder
- Fastening Type：Locking Ramp
- Contact Length - Mating：-
- Contact Length - Post：0.126" (3.20mm)
- Overall Contact Length：-
- Insulation Height：0.433" (11.00mm)
- Contact Shape：Square
- Contact Finish - Mating：Tin
- Contact Finish Thickness - Mating：100.0µin (2.54µm)
- Contact Finish - Post：Tin
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：Board Guide
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：Varies by Wire Gauge
- Voltage Rating：600VAC/DC
Download product information
Overview
The Amphenol ICC (FCI) part number 10127721-141LF is a Minitek Power 3.0 series power-to-board connector header. It features a dual-row vertical through-hole design with a 3 mm pitch and fourteen positions. The contacts are copper alloy with gold plating, rated for 8.5 A current and 600 VAC voltage. The housing is natural-colored liquid crystal polymer (LCP), supporting an operating temperature range from -40°C to +105°C. This component provides reliable high-current connections for board-level power distribution.
Feature Summary
- Dual-row vertical header configuration for compact power routing
- Gold-plated copper contacts ensure stable electrical conductivity
- Liquid crystal polymer housing offers thermal stability and flame resistance
Applications
- Server and storage equipment power distribution
- Telecommunications infrastructure boards
- Industrial control system power interfaces
Procurement Notes
Verify the specific ordering suffix against official Amphenol documentation to confirm contact plating and housing material variations. Ensure compatibility with mating sockets within the Minitek Power 3.0 family. Confirm that the vertical through-hole termination method aligns with your PCB assembly capabilities and soldering profiles.
Selection Notes
Select this component when a high-current 3 mm pitch solution is required for vertical board mounting. Consider the 14-position count and dual-row layout for space-constrained power applications. Verify that the 8.5 A rating meets the circuit requirements and that the LCP housing withstands the thermal environment of the final assembly process.
Part Context
This connector belongs to the Minitek Power 3.0 family, designed for robust power delivery in dense electronic environments. The series utilizes a 3 mm pitch to accommodate higher currents compared to signal connectors. As an FCI product now under Amphenol, it integrates established reliability standards for industrial and commercial applications requiring durable power interconnects.
Replacement Considerations
Compatible substitutes include other Minitek Power 3.0 headers with matching 3 mm pitch, 14 positions, and dual-row vertical configurations. Ensure any replacement maintains the same current rating and housing material specifications for mechanical and thermal consistency.
