Product Detailed Parameters
- Description：CONN PWR3.0 VT HEADER
- Series：Minitek® Pwr 3.0
- Mfr：Amphenol ICC (FCI)
- Package：Tray
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.118" (3.00mm)
- Number of Positions：18
- Number of Rows：2
- Row Spacing - Mating：0.118" (3.00mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Kinked Pin, Solder
- Fastening Type：Locking Ramp
- Contact Length - Mating：-
- Contact Length - Post：0.126" (3.20mm)
- Overall Contact Length：-
- Insulation Height：0.433" (11.00mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：30.0µin (0.76µm)
- Contact Finish - Post：Tin
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：Board Guide, Glow Wire Compliant
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：Varies by Wire Gauge
- Voltage Rating：600VAC/DC
Download product information
Overview
The Amphenol ICC (FCI) 10127721-184GLF is a Minitek Power 3.0 series power-to-board header connector designed for high-current applications. It features a double row configuration with 18 positions and a 3 mm pitch. The connector utilizes gold-plated copper contacts and a black Liquid Crystal Polymer (LCP) housing, rated for 600 VAC and 8.5 A per contact. It employs a through-hole solder pin termination style with straight mounting orientation. Operating within a temperature range of -40°C to +105°C, it provides reliable electrical interconnection in demanding environments.
Feature Summary
- Double-row design supporting high-density power distribution
- Gold-plated contacts ensuring stable conductivity
- LCP housing material offering thermal stability
Applications
- Server and storage equipment power distribution
- Telecommunications infrastructure boards
- Industrial control system power interfaces
Procurement Notes
Verify the specific suffix 'GLF' against official Amphenol documentation to confirm gold plating thickness and lead-free compliance status. Ensure the 18-position count matches the required circuit layout. Cross-reference the datasheet for any recent Product Change Notifications (PCN) that may affect material specifications or manufacturing locations prior to final procurement authorization.
Selection Notes
Select this component when a 3 mm pitch power header is required for board-to-board connections. Confirm that the PCB footprint supports the specified through-hole solder pin termination. Evaluate the 8.5 A current rating against the total load requirements of the application. Ensure the straight mounting angle aligns with the mechanical assembly constraints and mating connector height.
Part Context
This part belongs to the Minitek Power 3.0 family, a line of robust power connectors engineered by Amphenol FCI. The series is characterized by its 3 mm spacing and high current carrying capacity, making it suitable for critical power delivery in electronic systems. The 10127721 prefix identifies the specific header variant within this extensive product portfolio.
Replacement Considerations
Consult the official Amphenol cross-reference guide for verified substitute part numbers. Do not assume compatibility based on similar pitch or position counts alone. Verify that any alternative maintains the same voltage rating, current capacity, and termination style.
