10127820-0422LTLF

Overview

The 10127820-0422LTLF is a Minitek Pwr 4.2 power-to-board header manufactured by Amphenol ICC (FCI). It features a vertical surface-mount design with two rows and six positions. The connector utilizes brass contacts with gold plating and polyamide insulation rated UL94 V-0. It supports an operating temperature range of -40°C to +105°C and has a 4.2 mm pitch.

Feature Summary

• Vertical surface-mount termination for board integration
• Gold-plated brass contacts for reliable conductivity
• Polyamide insulation housing with UL94 V-0 flammability rating

Applications

• Communications equipment
• Data processing systems
• Consumer electronics
• Industrial instrumentation
• Military applications

Procurement Notes

Verify the specific suffix 'LTLF' against official Amphenol documentation to confirm lead-free status and material composition. Ensure compatibility with mating power connectors in the Minitek Pwr 4.2 series. Confirm current ratings align with system requirements, as these vary by wire gauge. Cross-reference datasheets for precise dimensional tolerances before procurement.

Selection Notes

Select this component for high-current power distribution where vertical mounting is required. The 4.2 mm pitch accommodates substantial conductors. Verify that the natural-colored polyamide housing meets thermal and mechanical constraints. Ensure the six-position configuration matches the circuit layout needs.

Part Context

This part belongs to the Minitek Pwr 4.2 series, designed for robust power connections. Amphenol ICC (FCI) produces this line for demanding environments requiring stable electrical performance. The series integrates signal and power capabilities across various industrial sectors.

Replacement Considerations

Consult official substitution lists for compatible headers within the Minitek Pwr 4.2 family. Verify pin count, pitch, and termination style match exactly before considering alternatives.
