10127820-0821CLF

Overview

The Amphenol ICC (FCI) 10127820-0821CLF is a Minitek Pwr4.2 series power connector designed for board-to-board applications. It features an unshrouded male header with a vertical orientation and a 4.2 mm pitch. The component provides 8 positions with a current rating of 9 A and a voltage rating of 600 V. Constructed with brass contacts plated in tin, it utilizes polyamide insulation. The connector supports through-hole termination and operates within a temperature range of -40°C to +105°C.

Feature Summary

• Vertical through-hole mounting configuration for direct board integration
• High current capacity of 9 A per contact for power distribution
• Tin-plated brass contacts ensuring reliable electrical conductivity
• Polyamide housing material providing thermal stability up to 105°C

Applications

• Industrial power distribution systems
• Factory automation equipment
• Heavy machinery control boards
• Alternative energy generation units

Procurement Notes

Verify the specific ordering suffix and contact plating requirements against the official datasheet before procurement. Confirm that the tin-plated variant meets the corrosion resistance needs of the target environment. Ensure the vertical header style aligns with the mechanical assembly constraints. Cross-reference the 8-position count with the design schematic to prevent mismatching during installation.

Selection Notes

Select this component when a high-current vertical interconnect is required for industrial or heavy-duty applications. The 4.2 mm pitch allows for robust spacing suitable for significant power loads. Consider the tin plating for cost-effective solutions where extreme corrosion resistance is not the primary constraint compared to gold variants. Ensure the operating temperature range fits the system's thermal profile.

Part Context

This part belongs to the Minitek Pwr4.2 series by Amphenol ICC (FCI), formerly Framatome Connectors International. The series specializes in power connectors offering high reliability and durability. FCI was acquired by Amphenol, continuing to provide specialized interconnect solutions for demanding environments including industrial, transportation, and data communication sectors.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with mating sockets from the same Minitek Pwr4.2 family. Check if alternative pitches or row configurations from other Amphenol series meet the spatial and electrical requirements.
