10127820-1022LF

Overview

The Amphenol ICC (FCI) 10127820-1022LF is a vertical power-to-board header from the Minitek Power4.2 series. It features 18 positions with a 4.2 mm pitch and dual rows. The connector utilizes brass contacts with tin plating, rated for 9 A current. Operating temperatures range from -40°C to +105°C, with an insulation resistance of 1 GOhms.

Feature Summary

• Vertical through-hole mounting configuration
• Dual-row design for high-density power distribution
• Tin-plated brass contacts for conductivity

Applications

• Industrial control systems
• Power supply modules
• Server infrastructure

Procurement Notes

Verify the specific pin count against the datasheet, as the model number may correspond to different position variants within the same series. Confirm that the tin contact finish meets the environmental requirements for the target application. Ensure the vertical orientation aligns with the board layout constraints.

Selection Notes

Select this component when a robust, high-current vertical interconnect is required. The 4.2 mm pitch accommodates larger conductors compared to standard signal headers. Verify compatibility with mating receptacles in the Minitek Power4.2 family to ensure proper mechanical engagement and electrical continuity.

Part Context

This part belongs to the Minitek Power4.2 series, designed for demanding power applications. It offers a reliable connection solution for PCBs requiring significant current handling capabilities. The series provides various position options to suit different power distribution needs.

Replacement Considerations

Check for direct substitutes within the Minitek Power4.2 line with matching pitch and row configuration. Ensure any replacement maintains the 9 A rating and vertical mounting style.
