Product Detailed Parameters
- Description：CONN HEADER VERT 4POS 2.54MM
- Series：EconoStik™ 10129378
- Mfr：Amphenol ICC (FCI)
- Package：Tape & Reel (TR)
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：4
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.318" (8.08mm)
- Contact Length - Post：0.090" (2.29mm)
- Overall Contact Length：0.508" (12.90mm)
- Insulation Height：0.100" (2.54mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：Pick and Place
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The 10129378-904004ALF is a vertical connector header manufactured by Amphenol ICC (FCI). It features 4 positions with a 0.100 inch (2.54mm) pitch. The component utilizes through-hole termination and square contact forms. Total length measures 0.508 inches (12.90mm).
Feature Summary
- Vertical orientation for standard board mounting.
- Through-hole termination method for secure attachment.
- Square contact form design.
Applications
- General electronic circuit interconnections.
- Industrial control systems.
- Consumer electronics assemblies.
Procurement Notes
Verify the specific manufacturer part number against official Amphenol documentation to ensure compatibility. Confirm that the 4-position, 2.54mm pitch configuration matches the target PCB footprint requirements before procurement.
Selection Notes
Select this component when a low-profile, vertical header with four contacts is required. Ensure the PCB layout supports through-hole assembly and accommodates the specified 0.100-inch spacing between pins for proper signal routing.
Part Context
This part belongs to the Amphenol ICC (FCI) line of rectangular connectors. FCI was acquired by Amphenol in 2016, integrating its extensive portfolio of interconnect solutions into the broader Amphenol Communications Solutions division for industrial and commercial markets.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Verify pin count and pitch compatibility if considering alternative manufacturers.
