10129380-906001ALF

Overview

The Amphenol ICC (FCI) part number 10129380-906001ALF is a surface-mount pin header from the Econostik series. It features a single row with six contacts and utilizes a 2.54 mm pitch. The connector is designed for board-to-board applications with straight termination. Rated for 3A current and 110VDC voltage, it operates within a temperature range of -55°C to 105°C. The housing is black thermoplastic with UL94 V-0 flammability rating, while contacts are copper alloy.

Feature Summary

• Surface mount straight termination design
• Unshrouded single-row configuration
• Thermoplastic insulation material

Applications

• General purpose electronic assemblies
• Industrial control systems
• Medical equipment interfaces
• Telecommunications hardware

Procurement Notes

Verify component authenticity through authorized Amphenol distributors or direct manufacturer channels. Confirm RoHS compliance status via official datasheets. Check for obsolescence notices as product lifecycle status may change. Ensure storage conditions maintain integrity of thermoplastic housing and contact plating prior to installation.

Selection Notes

Select this header for high-density board-to-board connections requiring surface mount reliability. The 2.54 mm pitch suits standard PCB layouts. Consider thermal management due to 105°C upper limit. Verify mechanical clearance for unshrouded contacts during assembly. Copper alloy contacts provide necessary conductivity for 3A ratings in compact form factors.

Part Context

This component belongs to the FCI Econostik family, known for cost-effective interconnect solutions. Amphenol acquired FCI in 2016, integrating these products into their ICC division. The series supports information, communication, and commercial electronics markets, emphasizing signal integrity and manufacturing efficiency for mass-produced devices.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
