10129380-908001ALF

Overview

The Amphenol ICC (FCI) part number 10129380-908001ALF is an EconoStik™ header connector designed for surface mount applications. It features a single row with eight positions and a 2.54mm pitch. The component supports a current rating of 3A and operates within a temperature range of -55°C to 105°C. It meets UL94 V-0 material flammability standards and utilizes black insulation.

Feature Summary

• Surface mount termination for automated PCB assembly
• EconoStik design supporting up to 50 mating cycles
• Suitable for industrial control and test equipment board-to-board connections

Applications

• Industrial control systems
• Test equipment interfaces
• Board-to-board interconnects

Procurement Notes

Verify the specific pin count and orientation against the official datasheet before integration. Confirm that the surface mount footprint matches the target PCB layout. Ensure the operating environment remains within the specified -55°C to 105°C thermal limits. Check for RoHS compliance requirements if applicable to the final assembly.

Selection Notes

Select this component when a low-cost, reliable header is required for non-critical signal or power distribution in industrial settings. The 2.54mm pitch offers standard spacing compatibility. Consider the 50-cycle mating limit for applications requiring frequent connection changes.

Part Context

This part belongs to the Amphenol FCI EconoStik series, which provides cost-effective interconnect solutions. The brand was acquired by Amphenol in 2016 and continues under the Amphenol ICC division. The series focuses on durable connectors for general-purpose electronic applications.

Replacement Considerations

Compatible substitutes include other 8-position, 2.54mm pitch SMD headers from manufacturers such as Molex or TE Connectivity. Ensure equivalent current ratings and thermal specifications are met when cross-referencing alternative components.
