Product Detailed Parameters
- Description：CONN HEADER SMD 8POS 2.54MM
- Series：EconoStik™ 10129380
- Mfr：Amphenol ICC (FCI)
- Package：Bulk
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：8
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Surface Mount
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.318" (8.08mm)
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.100" (2.54mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The 10129380-908002BLF is an EconoStik board-to-board connector header manufactured by Amphenol ICC (FCI). It features a single row with 8 positions and a 2.54 mm (0.100 inch) pitch. The component utilizes surface mount technology for vertical orientation and employs unshrouded male pins. Designed for reliable electrical interconnection, it supports applications requiring standard rectangular connector solutions within compact electronic assemblies.
Feature Summary
- Surface mount vertical configuration
- Single row unshrouded design
- EconoStik series construction
Applications
- Board-to-board interconnections
- General electronic equipment assembly
- Consumer electronics manufacturing
Procurement Notes
Verify the specific ordering suffix to confirm the exact contact finish and packaging type required for your production line. Ensure compatibility with automated pick-and-place equipment due to the surface mount package style. Cross-reference the pin count and pitch against the target PCB footprint to guarantee mechanical alignment before procurement.
Selection Notes
Select this component when a low-profile, cost-effective vertical header is needed for single-row connections. The 2.54 mm pitch ensures broad compatibility with standard through-hole mating connectors. Consider the unshrouded design for space-constrained layouts where side clearance is available.
Part Context
This part belongs to the Amphenol FCI EconoStik family, which provides economical interconnect solutions. Amphenol acquired FCI in 2016, integrating its extensive connector portfolio into the Amphenol ICC division. This series focuses on delivering reliable performance for high-volume consumer and industrial applications.
Replacement Considerations
Direct substitutes must match the 8-position count, 2.54 mm pitch, and surface mount vertical form factor. Verify that alternative headers maintain identical unshrouded pin configurations and compatible solder termination methods to ensure seamless PCB integration.
