Product Detailed Parameters
- Description：CONN HEADER SMD 10POS 2.54MM
- Series：EconoStik™ 10129380
- Mfr：Amphenol ICC (FCI)
- Package：Tape & Reel (TR),Cut Tape (CT)
- Connector Type：Header, Cuttable
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：10
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Surface Mount
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.318" (8.08mm)
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.100" (2.54mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：1.00µin (0.025µm)
- Contact Finish - Post：-
- Contact Material：Copper Alloy
- Insulation Material：Thermoplastic
- Features：-
- Operating Temperature：-55°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：110VDC
Download product information
Overview
The Amphenol ICC (FCI) part number 10129380-910002ALF is a rectangular header connector belonging to the EconoStik series. It features a single row of ten male pins with a 2.54mm pitch, designed for surface mount termination. The connector supports a rated current of 3A and operates within a temperature range of -55°C to 105°C. Constructed with thermoplastic insulation and copper alloy contacts finished with gold plating, it provides reliable electrical interconnection for printed circuit boards.
Feature Summary
- Surface mount termination style for automated PCB assembly
- Cuttable header design allowing for flexible pin count configuration
- Gold-plated copper alloy contacts ensuring signal integrity
Applications
- General purpose electronic equipment interconnections
- Consumer electronics internal wiring
- Industrial control board connections
Procurement Notes
Verify the specific contact finish thickness and material composition against the official datasheet before integration. Confirm that the surface mount footprint matches the target PCB layout dimensions. Ensure the operating temperature range aligns with the environmental requirements of the final application to guarantee long-term reliability.
Selection Notes
Select this component when a low-cost, single-row header with surface mount capability is required. The 2.54mm pitch is standard for many legacy and general-purpose designs. Consider the cuttable feature if custom pin counts are needed. Evaluate the 3A current rating against the maximum load of the circuit to prevent overheating during operation.
Part Context
This connector is part of the EconoStik family, which focuses on cost-effective solutions for mass-market electronics. The series offers various configurations including through-hole and surface mount options. The 10129380 series specifically targets applications requiring reliable performance at competitive price points without sacrificing essential electrical specifications.
Replacement Considerations
Direct substitutes may include other 10-position, 2.54mm pitch SMD headers from manufacturers such as Molex or Samtec. Verify mechanical compatibility and electrical ratings before substitution. Cross-reference the datasheet for any differences in peak reflow temperature profiles or soldering recommendations.
