10129381-906003BLF

$0.13

Description：CONN HEADER VERT 6POS 2.54MM
Series：EconoStik™ 10129381
Mfr：Amphenol ICC (FCI)
Package：Bulk

SKU:d9672ee147f8 Category: Headers, Male Pins Brand: Amphenol ICC (FCI)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN HEADER VERT 6POS 2.54MM
Series：EconoStik™ 10129381
Mfr：Amphenol ICC (FCI)
Package：Bulk
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：6
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.318" (8.08mm)
Contact Length - Post：0.120" (3.05mm)
Overall Contact Length：0.538" (13.67mm)
Insulation Height：0.100" (2.54mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：1.00µin (0.025µm)
Contact Finish - Post：-
Contact Material：Copper Alloy
Insulation Material：Thermoplastic
Features：-
Operating Temperature：-55°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：110VDC

Download product information

10129381-906003BLF

Overview

The Amphenol ICC (FCI) part number 10129381-906003BLF is a 6-position vertical through-hole header connector from the EconoStik™ series. It features a 2-row configuration with a 0.100-inch (2.54mm) pitch. The connector utilizes thermoplastic insulation and copper alloy contacts rated for 3A current. Operating temperature ranges from -55°C to 105°C, with UL 94 V-0 flammability rating.

Feature Summary

Vertical board-to-board or cable connection design
Cuttable solder bulk through-hole termination
Copper alloy contact material for conductivity

Applications

General electronic equipment interconnects
Industrial control systems
Consumer electronics assemblies

Procurement Notes

Verify the specific suffix 'BLF' against official datasheets to confirm plating and packaging details. Ensure compatibility with mating headers regarding row spacing and pin count. Confirm RoHS compliance status as indicated in distributor listings versus manufacturer specifications.

Selection Notes

Select this component for applications requiring standard 2.54mm pitch vertical headers. Consider the 3A current rating and thermoplastic insulation properties. Verify mechanical fit within the assembly space constraints for a 2-row, 6-position layout.

Part Context

This connector belongs to the EconoStik™ series by Amphenol ICC (FCI), formerly FCI. The series provides cost-effective solutions for board-to-board and cable connections. Amphenol acquired FCI in 2016, integrating these products into their broader interconnect portfolio.
