10129381-910003BLF

Overview

The Amphenol ICC (FCI) part number 10129381-910003BLF is a board-to-board connector header designed for through-hole mounting. It features a 2-row configuration with 10 positions and a 2.54 mm pitch. The contacts are gold-plated copper alloy pins rated for 3 A current and UL 94 V-0 flammability.

Feature Summary

• Through-hole termination method ensures secure PCB attachment.
• Gold-plated contact surfaces provide reliable signal transmission.
• Straight pin header design facilitates standard vertical board stacking.

Applications

• General electronic equipment interconnections
• Industrial control system circuit boards
• Consumer electronics internal wiring

Procurement Notes

Verify the specific ordering suffix against the official datasheet to confirm row count, pin position, and plating specifications. Ensure compatibility with mating receptacles regarding pitch and mechanical retention requirements before finalizing procurement orders.

Selection Notes

Select this component when a low-profile, two-row straight header is required for direct board-to-board connections. Consider the 2.54 mm spacing and through-hole assembly constraints during the layout phase to ensure adequate clearance and soldering accessibility.

Part Context

This component belongs to the Amphenol ICC (FCI) portfolio of communication connectors. It serves as a standard interconnect solution within their broader range of board-level hardware, supporting various industrial and commercial electronic applications requiring robust electrical continuity.

Replacement Considerations

Direct substitutes must match the 2x10 pin count, 2.54 mm pitch, and through-hole termination style. Verify that alternative headers maintain identical gold plating thickness and UL 94 V-0 ratings to ensure equivalent performance and safety compliance.
