10129381-912002BLF

Overview

The Amphenol ICC (FCI) part number 10129381-912002BLF is a header connector belonging to the EconoStik series. It features a vertical through-hole termination style with a 2.54 mm pitch and two rows of contacts, totaling twelve positions. The connector utilizes male pin contact types designed for board-to-board or cable applications. The housing is constructed from thermoplastic material, providing structural integrity for standard electronic assemblies.

Feature Summary

• Vertical orientation facilitates direct printed circuit board mounting
• Thermoplastic housing ensures reliable insulation properties
• Male pin configuration supports secure mating connections

Applications

• General purpose electronic assemblies
• Industrial control systems
• Consumer electronics manufacturing

Procurement Notes

Verify the specific suffix BLF against official datasheets to confirm plating specifications and color coding. Ensure compatibility with mating receptacles regarding current ratings and mechanical retention requirements before finalizing procurement decisions.

Selection Notes

Select this component when a low-profile, cost-effective vertical header is required. The 2.54 mm pitch allows for standard spacing layouts. Confirm that the twelve-position count aligns with signal routing needs and that the through-hole termination matches the target board fabrication capabilities.

Part Context

This connector belongs to the EconoStik family, which focuses on providing economical interconnect solutions for high-volume production environments. The series emphasizes reliability and ease of assembly while maintaining consistent electrical performance across various industrial and commercial applications.

Replacement Considerations

Direct substitutes include other 12-pin, 2-row, 2.54 mm pitch headers from the same manufacturer. Verify mechanical dimensions and terminal plating equivalence to ensure functional interchangeability without redesigning the host board.
